ANVISION 40mm x 10mm DC 12V Brushless Cooling Fan, Dual Ball Bearing, 2 Pin
Product details
| Management number | 212168075 | Release Date | 2026/04/06 | List Price | $2.84 | Model Number | 212168075 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Dimension: 40*40*10mm Housing: Black PBT (UL94V-0) Fan Blade: 7 Blades, Black PBT (UL94V-0) Bearing System: Two Ball Bearings Net Weight: 13.7g Rated Voltage: 12V DC Operating Voltage Range: 10.8-13.2V DC Start-up Voltage: 6.0V DC Rated Current: 0.04A (0.10A Max.) Rated Power: 0.48W (1.2W Max.) Rated Speed: 6200PRM Air Flow: 7.56CFM Air Pressure: 3.19mmH2O *Noise Level: 27.50dB(A) Lift Expectancy: 50000H at 25degree test *Acoustical Noise Testing Condition: Fan is hanged in anechoic chamber, noise is measured at rated voltage in anechoic chamber with microphone at a distance of 1 meter formthe air intake.
- Rated Voltage: 12V DC, Current: 0.1A
- Airflow: 7.56CFM, Speed: 6200RPM, Noise: 27.50dBA
- Bearing Type: Dual Ball Bearing
- Dimension: 40mm x 40mm x 10mm (1.57inch x 1.57inch x 0.39inch), Lead Wire: 2-pin-2.5mm connector, length: 150mm/5.90inch;
- Warranty: two years
| Voltage | 12 Volts (DC) |
|---|---|
| Brand Name | ANVISION |
| Unit Count | 1.0 Count |
| Noise Level | 27.5 Decibels |
| Manufacturer | ANVISION INC |
| Material Type | Plastic |
| Cooling Method | Air |
| Air Flow Capacity | 7.56 Cubic Feet Per Minute |
| Compatible Devices | Server |
| Power Connector Type | 2-Pin |
| Maximum Rotational Speed | 6200 RPM |
| Item Dimensions L x W x H | 1.57"L x 0.39"W x 1.57"H |
